- Place of Origin:CHINA
- Input Voltage(V):100V-264V/47-63HZ
- Lamp Power(W):70
- Working Lifetime(Hour):5K-100000
- Brand Name:DAISEYA
- Model Number:P1007-UV
Detailed Product Description
Color: | UV | Light Source: | 10WCOB UV LED |
PowerConsume: | 70W | Control Signal: | DMX512 |
IP Rating: | IP65 | Control mode: | StandAlone/ Master Slave |
Channel: | 3CH,1CH | Function Effect: | dimmer, strobe, gradual change,rainbow,self program |
Description:
The P1007-UV is the ideal workhorse for every purpose. The LED fixture has an outstanding smooth 10W UV color delivered by 7 high power LEDs with a very punchy 25° beam angle. The special selected LEDs provides high output with intense colors. IP65 rating makes the P1007-UV suitable for both in- and outdoor use.
The P1007-UV comes with a unique design featuring a single bracket with both standing as hanging capabilities. Besides that, the solid housing makes the P1007-UV the perfect solution for heavy on the road use.
The fixture is equipped with an OLED screen for easy access to the on-board settings. Silent operation is ensured because of the intelligent cooling system. Data and power can be connected through the IP65 3p XLR and PowerCON TRUE1 connectors and rigging is made easy by the iconic CLF quick lock system.
Specification:
Input voltage: AC 100V-264V/47-63HZ
Power Consumption:80W
Lamp Type:10W COB UV LED(7PCS)
Life span: 50000~100000hours
PWM Dimmer:4200HZ(16666 grades)
Control Signal:DMX512
Control mode:stand alone/ Master/Slaver
Channel:3CH,1CH
Function Effect: dimmer, strobe, gradual change, rainbow, self program running
Built-In temperature control measurement function, when LED work overheated, Intelligent reduce LED output power, current power output and temperature can be viewed.
Cooling mode: Natural Convection
Anti-electricity Intension:1.5KV
Insulation Resistance:>2MΩ
IP Rate: IP65
Dimension: 335*338*225mm
N.W.: 7.2Kg
